Feature
◆ Excellent mechanical endurance
◆ Low Insertion Loss
◆ Good in repeatability
Specifications
|
|
Dust Cap Color |
Connector Type |
Connector Color |
Boot Type |
Boot Color |
|
End A ( FC ) |
Transparent |
FC/APC FC/UPC FC/PC |
Silver |
Standard |
Green Blue and Yellow Black and Red |
|
|
Dust Cap Color |
Connector Type |
Connector Color |
Boot Type |
Boot Color |
|
End B ( SC ) |
Transparent |
SC/APC SC/UPC SC/PC |
Blue Green Beige Aqua Violet |
Standard |
Green Blue and Yellow Red and Black |
|
|
Fiber Type |
Cable Type |
Cable OD |
Jacket Color |
Jacket Material |
|
Cable |
SM G652D 9/125 SM G657A1 9/125 SM G657A2 9/125 MM OM1 62.5/125 MM OM2 50/125 MM OM3 50/125 MM OM4 50/125 MM OM5 50/125 |
Duplex |
2.0X4.1mm 2.8X5.7mm |
Yellow Grey Orange Aqua Violet Lime Green
|
LSZH |
Technical Data
| Fiber Type | Connector Type | Insertion Loss | Return | Repeatability | Durability | Operating temperature |
| SM | UPC | ≤0.2dB | ≥55dB | ≤0.2dB | ＞500 | -20~75℃ |
| APC | ≥65dB | |||||
| MM | PC | ≤0.1dB | / |
