Feature
◆ Excellent mechanical endurance
◆ Low Insertion Loss
◆ Good in repeatability
Specifications
|
|
Dust Cap Color |
Connector Type |
Connector Color |
Boot Type |
Boot Color |
|
End A ( LC ) |
Beige or Customized |
LC/UPC LC/APC LC/PC |
Blue Green Beige Aqua Violet Lime Green |
Standard |
Beige Green |
|
End B ( SC ) |
Dust Cap Color |
Connector Type |
Connector Color |
Boot Type |
Boot Color |
|
Transparent |
SC/UPC SC/APC SC/PC |
Blue Green Beige Aqua Violet |
Standard |
Green Blue and Yellow Red and Black |
|
|
Cable |
Fiber Type |
Cable Type |
Cable OD |
Jacket Color |
Jacket Material |
|
SM G652D 9/125 SM G657A1 9/125 SM G657A2 9/125 MM OM1 62.5/125 MM OM2 50/125 MM OM3 50/125 MM OM4 50/125 MM OM5 50/125 |
Armored Round |
3.0mm |
Grey Blue or Customized |
LSZH PVC |
Technical Data
|
Fiber Type |
Connector Type |
Insertion Loss |
Return Loss |
Repeatability |
Durability |
Operating temperature |
|
SM |
UPC |
≤0.2dB |
≥55dB |
≤0.2dB |
＞500 |
-20~75℃ |
|
APC |
≥65dB |
|||||
|
MM |
PC |
≤0.1dB |
/ |
